TE Connectivity – Red Butt Splice Terminal 16-22AWG 32.13mm Tin | 320559

The Tyco AMP 320559 Terminal is a standard, unsealed butt splice for wire AWG 22-16. It has a Pre-insulated Diamond Grip (PIDG) body made from copper with a tin finish, and red nylon insulation. Set comes with 50 pieces.

Approvals/References/Specification

• Pilatus Aircraft Part Number: 971.31.32.602
• US Military Specification: M7928/5-3

Product Type Features

• Product Type: Splice
• Sealed: No
• Splice Type: Butt
• Body Style: PIDG
• Insulation: Yes
• Insulation Support: Insulation Support
• Insulation Diameter (mm [in]): 3.18 [.125] Max.
• Material: Copper
• Finish: Tin
• Color: Red

This TE Connectivity butt splice terminal is great for joining 16 – 22AWG wires. Here’s how to use it: First, strip the insulation from the wires you want to connect. Then, insert the stripped ends into the terminal. Make sure they fit snugly. Since it’s not sealed, keep it dry to avoid any issues. For maintenance, just check that the connections are still secure over time. If you’re working on a project that requires a standard butt splice for these wire gauges, this 50-piece set with its red nylon-insulated, tin-coated copper terminals is a convenient choice.
